1． Thebuilt-in omron PLC programmable controller has the functions of safetyprotection and fault alarm, which improves the operation stability of themachine.
2． Thesealing and cutting knife adopts American Dupont Teflon anti-stick coating, thesealing won't crack and won't coking; Sealing cutter with automatic protectionfunction, can prevent the wrong cutting packaging
3． Sensorfeeding film, greatly reduce the loss of film
4． UsingOmron digital display temperature controller, can set the temperature, sealingand cutting temperature is very sensitive and accurate
5． Automaticfeeding, bag-making length is automatically controlled by the combination ofsensor and timer
6． Accordingto production requirements for different products replacement, modular design,more convenient replacement
7． BM-6040adopts double blower motor, heat is evenly heated in the furnace cavity, andthe shrinkage effect is more beautiful
8． Adoptfrequency converter to control transmission speed and stepless speed regulation
9． Adoptroller conveyor belt and roller outer heat-resistant silicone tube, each ofwhich can rotate freely to achieve the best shrinkage effect
|
Model |
BTX-6040 |
BM-6040 |
|
voltage |
220-240V/50-60Hz |
3Phase 220V,380-460V/50-60Hz |
|
max packing size |
(L)600×(W)400×(H)250mm |
(L)600×(W)400×(H)250mm |
|
speed |
8-12sets/min |
15 meters/min |
|
air pressure |
1HP/2kw |
/ |
|
conveyor width |
300mm |
/ |
|
max current |
3A |
50A |
|
Shrink tunnel size |
/ |
(L)1800×(W)600×(H)400mm |
|
machine size |
(L)1750×(W)1260×(H)1875mm |
(L)2750×(W)840×(H)1550mm |
|
machine weight |
300kg |
850kg |
